Dell WD22TB4 Thunderbolt 4 Dock 180W - 40Gbps, 3-Year Warranty, USB-C Dell Docking Station with 180W Adapter + Techtray Cables & Cloth - Supports Dual/Triple Monitor & 4K Displays (New)

About This

• [CHECK COMPATIBILITY FIRST] - Requires a laptop with Thunderbolt 4, Thunderbolt 3, USB4, or USB-C with DisplayPort Alt Mode. Provides up to 130W power delivery to Dell laptops and 90W to non-Dell systems. Gaming laptops requiring 180W+ must keep their OEM charger connected for heavy workloads. NOT a host connection for USB-A-only laptops, tablets, or phones. Base M1/M2/M3 MacBooks support ONE external display through any dock — a system limit, not a dock fault. Confirm your laptop's charging requirements and ports first.
• [MONITOR SUPPORT DEPENDS ON YOUR LAPTOP] - Outputs via 2x DisplayPort 1.4, 1x HDMI 2.0, and USB-C DisplayPort Alt Mode. Thunderbolt 4 and 3 hosts have the bandwidth for dual and triple displays. USB-C DP Alt Mode hosts may be limited to fewer screens or lower resolution. For macOS users: confirm the external-display limit for your exact chip first. (Note: HDMI and USB-C Alt Mode ports are shared/muxed - only use one at a time)
• [PORTS & SLOTS] - This dock features a total of 13 ports & slots: - Sleep/Wake up/Power button. - 1x USB 3.2 Gen 2 Type-C port, 1x USB 3.2 Gen 1 port with PowerShare. - 2x DisplayPort 1.4, 1x HDMI 2.0, 1x USB 3.2 Gen 2 Type-C port with DisplayPort 1.4 Alt Mode, 2x USB 3.2 Gen 1 ports, 1x Gigabit Ethernet Network connector (RJ-45), 1x Power Connector, & 2x Thunderbolt 4 ports (40 Gbps, 15 W) incl. Thunderbolt 4 host port (40 Gbps, 130 W power delivery). - 1x Wedge-shaped lock slot, 1x Kensington security-cable slot
• [OS Compatibility] - For Windows 10, Windows 11, Ubuntu OS, Chrome OS, macOS (with Thunderbolt 3 or 4 enabled Macs) / Comes with 180W Power Adapter / 120/230 V AC (50/60 Hz)
• [Device Compatibility] - Compatible with USB Type-C Thunderbolt systems and USB Type-C systems with DisplayPort Alt Mode, including laptops with larger screens. For macOS users, they can connect one 4K 60Hz display directly, while dual monitors may need DisplayLink. M1 Pro and M1 Max Macs support two 4K 60Hz displays, but original M1 and M2 Macs allow only one external display because of system limitations

Overview

• Brand : TechTray
• Color : Black
• Hardware Interface : DisplayPort, Ethernet, HDMI, Thunderbolt 4, USB 3.2 Gen 1, USB 3.2 Gen 2, USB Type C
• Compatible Devices : Compatible with USB Type-C, Thunderbolt Systems, Thunderbolt 4, Thunderbolt 3, USB4 Devices
• Total USB Ports : 5
• Number of Ports : 11
• Total HDMI Ports : 1
• Wattage : 180
• Input Voltage : 120 volts
• Number of Items : 6
